| Item | Unit | Parameter | ||
|---|---|---|---|---|
| Power supply | Voltage/Phase/Frequency | 380V/3P/50Hz | ||
| Refrigerant | R404A | |||
| Temperature | Ambient Temperature | ℃ | 35 | |
| Water Temperature | ℃ | 20 | ||
| Operating Power | Total running power | kw | 12.617 | |
| Power of Reducer | kw | 0.37 | ||
| Power of Cold Water Pump | kw | 0.03 | ||
| Capacity/Stock | Capacity | kg/24h | 2500 | |
| Capacity of Ice Bin | kg | 1100 | ||
| Compressor | Manufacturer | Copeland | ||
| Refrigeration Power | kw | 15 | ||
| Operating Power | kw | 11.9 | ||
| Compressor COP/EER | kw/kw | 1.16 | ||
| Horse Power | hp | 12 | ||
| Condenser | Fan Power | kw | 0.45 | |
| Cooling Way | Air Cooling | |||
| Dimension | Size of Ice Maker | L×W×H(mm) | 1560×1200×1150 | |
| Size of Ice Bin | L×W×H(mm) | 1600×1400×950 | ||
| Size of Feeding Pipe | 4" | |||
| Weight | Weight of Flake Ice Maker | kg | 550 | |
| Operating Weight of Ice Bin | kg | 1200 | ||
| Water Supply Pressure Requirement | bar | 1~6 | ||
