| Item | Unit | Parameter | |
|---|---|---|---|
| Power supply | Voltage/Phase/Frequency | 380V/3P/50Hz | |
| Refrigerant | R22 or R404A | ||
| Capacity | kg/24h | 35000 | |
| Cooling Way | Water Cooling | ||
| Temperature | Ambient Temperature | ℃ | 35 |
| Water Temperature | ℃ | 20 | |
| Compressor | Manufacturer | Bitzer/Carrier | |
| Refrigeration Power | kw | 198 | |
| Operating Power | kw | 101.2 | |
| Compressor COP/EER | kw/kw | 1.94 | |
| Horse Power | hp | 75×2types | |
| Operating power | Total running power | kw | 115.35 |
| Installation Power | kw | 140 | |
| Power of Reducer | kw | 2.2 | |
| Power of Cold Water Pump | kw | 0.75 | |
| Cooling Water Pump | kw | 7.5 | |
| Fan of Cooling Tower | kw | 3.7 | |
| Dimension | Size of Ice Maker | L×W×H(mm) | Unit: 2800×2200×2200 |
| Evaporator: 2400×2000×3200 | |||
| Size of Cooling Tower | L×W×H(mm) | Φ3300×2785 | |
| Size of Water Feeding Pipes of Cooling Tower | 1" | ||
| Size of Cooling Water Pipes | 5" | ||
| Size of Feeding Pipe | 1" | ||
| Size of Ice Outlet | mm | Φ2160 | |
| Weight | Weight of Flake Ice Maker | kg | Unit: 2800 |
| Evaporator: 4600 | |||
| Operating Weight of Cooling Tower | kg | 2730 | |
| Water Supply Pressure Requirement | bar | 1~6 | |
