| Item | Unit | Parameter | ||||
|---|---|---|---|---|---|---|
| Power supply | Voltage/Phase/Frequency | 380V/3P/50Hz | ||||
| Refrigerant | R404A | |||||
| Capacity | kg/24h | 15000 | ||||
| Cooling Way | Water Cooling | |||||
| Temperature | Ambient Temperature | ℃ | 35 | |||
| Water Temperature | ℃ | 20 | ||||
| Compressor | Manufacturer | Bitzer/Carrier | ||||
| Refrigeration Power | kw | 83.8 | ||||
| Operating Power | kw | 44 | ||||
| Compressor COP/EER | kw/kw | 1.9 | ||||
| Horse Power | hp | 40×2types | ||||
| Operating power | Total running power | kw | 49.35 | |||
| Installation Power | kw | 60 | ||||
| Power of Reducer | kw | 1.5 | ||||
| Power of Cold Water Pump | kw | 0.55 | ||||
| Cooling Water Pump | kw | 2.2 | ||||
| Fan of Cooling Tower | kw | 1.1 | ||||
| Dimension | Size of Ice Maker | L×W×H(mm) | 4000×1850×2400 | |||
| Size of Cooling Tower | L×W×H(mm) | ￠2000×2410 | ||||
| Size of Water Feeding Pipes of Cooling Tower | 6" | |||||
| Size of Cooling Water Pipes | 2.5" | |||||
| Size of Feeding Pipe | 6" | |||||
| Size of Ice Outlet | mm | ￠1280 | ||||
| Weight | Weight of Flake Ice Maker | kg | 3200 | |||
| Weight of Container | kg | 2500 | ||||
| Water supply pressure requirement | bar | 1~6 | ||||
